The Search Job Inspector can be used to expand the following sections: Search job properties and Optimization suggestions. The Search Job Inspector is a tool that provides detailed information about a search job, such as the search parameters, the search statistics, the search timeline, and the search log. The Search Job Inspector can be accessed by clicking the Job menu in the Search bar and selecting Inspect Job. The Search Job Inspector has several sections that can be expanded or collapsed by clicking the arrow icon next to the section name. The Search job properties section shows the basic information about the search job, such as the SID, the status, the duration, the disk usage, and the scan count. The Optimization suggestions section shows the suggestions for improving the search performance, such as using transforming commands, filtering events, or reducing fields. The Execution costs and Saved search history sections are not part of the Search Job Inspector, and they cannot be expanded. The Execution costs section is part of the Search Dashboard, which shows the relative costs of each search component, such as commands, lookups, or subsearches. The Saved search history section is part of the Saved Searches page, which shows the history of the saved searches that have been run by the user or by a schedule

Number of concurrent users: This is an important factor because it affects the search performance and resource utilization of the Splunk environment. More users mean more concurrent searches, which require more CPU, memory, and disk I/O. The number of concurrent users also determines the search head capacity and the search head clustering configuration12

Volume of incoming data: This is another crucial factor because it affects the indexing performance and storage requirements of the Splunk environment. More data means more indexing throughput, which requires more CPU, memory, and disk I/O. The volume of incoming data also determines the indexer capacity and the indexer clustering configuration13

Existence of premium apps: This is a relevant factor because some premium apps, such as Splunk Enterprise Security and Splunk IT Service Intelligence, have additional requirements and recommendations for the Splunk environment. For example, Splunk Enterprise Security requires a dedicated search head cluster and a minimum of 12 CPU cores per search head. Splunk IT Service Intelligence requires a minimum of 16 CPU cores and 64 GB of RAM per search head45

 Search head clustering is a Splunk feature that allows a group of search heads to share configurations, apps, and knowledge objects, and to provide high availability and scalability for searching. Search head clustering has the following characteristics:

A deployer is required. A deployer is a Splunk instance that distributes the configurations and apps to the members of the search head cluster. The deployer is not a member of the cluster, but a separate instance that communicates with the cluster master.

At least three search heads are needed. A search head cluster must have at least three search heads to form a quorum and to ensure high availability. If the cluster has less than three search heads, it cannot function properly and will enter a degraded mode.

The deployer must have sufficient CPU and network resources to process service requests and push configurations. The deployer is responsible for handling the requests from the cluster master and the cluster members, and for pushing the configurations and apps to the cluster members. Therefore, the deployer must have enough CPU and network resources to perform these tasks efficiently and reliably.

Search heads do not need to meet the high-performance reference server requirements, as this is not a mandatory condition for search head clustering. The high-performance reference server requirements are only recommended for optimal performance and scalability of Splunk deployments, but they are not enforced by Splunk.

Comprehensive and Detailed Explanation (From Splunk Enterprise Documentation)Splunk Enterprise documentation clarifies that none of the listed configurations are prohibited in production. Splunk allows the Cluster Manager to be colocated with the Monitoring Console in small deployments because both are management-plane functions and do not handle ingestion or search traffic. The documentation also states that the Search Head Cluster Deployer is not a runtime component and has minimal performance requirements, so it may be colocated with the Monitoring Console or Licensing Master when hardware resources permit.

Splunk also supports virtual machines for both search heads and indexers, provided they are deployed with dedicated CPU, storage throughput, and predictable performance. Splunk’s official hardware guidance specifies that while bare metal often yields higher performance, virtualized deployments are fully supported in production as long as sizing principles are met.

Because Splunk explicitly supports all four configurations under proper sizing and best-practice guidelines, there is no correct selection for “unsupported.” The question is outdated relative to current Splunk Enterprise recommendations.

According to the Splunk documentation1, determining data capacity for an index is a complex task that depends on several factors, such as:

Average size of event data. This is the average number of bytes per event that you send to Splunk. The larger the events, the more storage space they require and the more indexing time they consume.

Number of data sources. This is the number of different types of data that you send to Splunk, such as logs, metrics, network packets, etc. The more data sources you have, the more diverse and complex your data is, and the more processing and parsing Splunk needs to do to index it.

Peak data rates. This is the maximum amount of data that you send to Splunk per second, minute, hour, or day. The higher the peak data rates, the more load and pressure Splunk faces to index the data in a timely manner.

The other option is false because:

Number of concurrent searches on data. This is not a factor that affects daily indexing volume, as it is related to the search performance and the search scheduler, not the indexing process. However, it can affect the overall resource utilization and the responsiveness of Splunk2.

Primary rebalancing automatically occurs when a rolling restart completes, a master node rejoins the cluster, or a peer node joins or rejoins the cluster. These events can cause the distribution of primary buckets to become unbalanced, so the master node will initiate a rebalancing process to ensure that each peer node has roughly the same number of primary buckets. Primary rebalancing does not occur when a captain joins or rejoins the cluster, because the captain is a search head cluster component, not an indexer cluster component. The captain is responsible for search head clustering, not indexer clustering

A deployment plan should include business continuity and disaster recovery plans, current logging details and data source inventory, and current and future topology diagrams of the IT environment. These elements are essential for planning, designing, and implementing a Splunk deployment that meets the business and technical requirements. A comprehensive list of stakeholders, either direct or indirect, is not part of the deployment plan, but rather part of the project charter. For more information, see Deployment planning in the Splunk documentation.

 The following statements are true about Splunk indexer clustering:

All peer nodes must run exactly the same Splunk version. This is a requirement for indexer clustering, as different Splunk versions may have different data formats or features that are incompatible with each other. All peer nodes must run the same Splunk version as the master node and the search heads that connect to the cluster.

The search head must run the same or a later Splunk version than the peer nodes. This is a recommendation for indexer clustering, as a newer Splunk version may have new features or bug fixes that improve the search functionality or performance. The search head should not run an older Splunk version than the peer nodes, as this may cause search errors or failures. The following statements are false about Splunk indexer clustering:

The master node must run the same or a later Splunk version than the search heads. This is not a requirement or a recommendation for indexer clustering, as the master node does not participate in the search process. The master node should run the same Splunk version as the peer nodes, as this ensures the cluster compatibility and functionality.

The peer nodes must run the same or a later Splunk version than the master node. This is not a requirement or a recommendation for indexer clustering, as the peer nodes do not coordinate the cluster activities. The peer nodes should run the same Splunk version as the master node, as this ensures the cluster compatibility and functionality. For more information, see [About indexer clusters and index replication] and [Upgrade an indexer cluster] in the Splunk documentation.

Within the [clustering] stanza of the server.conf file, the mode attribute defines the functional role of a Splunk instance within an indexer cluster. Splunk documentation identifies three valid modes:

mode = manager

Defines the node as the Cluster Manager (formerly called the Master Node).

Responsible for coordinating peer replication, managing configurations, and ensuring data integrity across indexers.

mode = peer

Defines the node as an Indexer (Peer Node) within the cluster.

Handles data ingestion, replication, and search operations under the control of the manager node.

mode = searchhead

Defines a Search Head that connects to the cluster for distributed searching and data retrieval.

The value “deployer” (Option C) is not valid within the [clustering] stanza; it applies to Search Head Clustering (SHC) configurations, where it is defined separately in server.conf under [shclustering].

Each mode must be accompanied by other critical attributes such as manager_uri, replication_port, and pass4SymmKey to enable proper communication and security between cluster members.

References (Splunk Enterprise Documentation):

• Indexer Clustering: Configure Manager, Peer, and Search Head Modes

• server.conf Reference – [clustering] Stanza Attributes

• Distributed Search and Cluster Node Role Configuration

• Splunk Enterprise Admin Manual – Cluster Deployment Architecture

When building a deployment plan, the architect should perform the following tasks:

Use case checklist. A use case checklist is a document that lists the use cases that the deployment will support, along with the data sources, the data volume, the data retention, the data model, the dashboards, the reports, the alerts, and the roles and permissions for each use case. A use case checklist helps to define the scope and the functionality of the deployment, and to identify the dependencies and the requirements for each use case1

Inventory data sources. An inventory of data sources is a document that lists the data sources that the deployment will ingest, along with the data type, the data format, the data location, the data collection method, the data volume, the data frequency, and the data owner for each data source. An inventory of data sources helps to determine the data ingestion strategy, the data parsing and enrichment, the data storage and retention, and the data security and compliance for the deployment1

Review network topology. A review of network topology is a process that examines the network infrastructure and the network connectivity of the deployment, along with the network bandwidth, the network latency, the network security, and the network monitoring for the deployment. A review of network topology helps to optimize the network performance and reliability, and to identify the network risks and mitigations for the deployment1

Installing Splunk apps is not a task that the architect should perform when building a deployment plan, as it is a task that the administrator should perform when implementing the deployment plan. Installing Splunk apps is a technical activity that requires access to the Splunk instances and the Splunk configurations, which are not available at the planning stage

Splunk provides various methods to change the internal logging levels in a Splunk environment to troubleshoot an issue. All of the options are valid ways to do so. Option A is correct because the Monitoring Console (MC) allows the administrator to view and modify the logging levels of various Splunk components through a graphical interface. Option B is correct because the Splunk command line provides the splunk set log-level command to change the logging levels of specific components or categories. Option C is correct because the Splunk Web provides the Settings > Server settings > Server logging page to change the logging levels of various components through a web interface. Option D is correct because the log-local.cfg file allows the administrator to manually edit the logging levels of various components by overriding the default settings in the log.cfg file123

1: https://docs.splunk.com/Documentation/Splunk/9.1.2/Troubleshooting/Enabledebuglogging 2: https://docs.splunk.com/Documentation/Splunk/9.1.2/Admin/Serverlogging 3: https://docs.splunk.com/Documentation/Splunk/9.1.2/Admin/Loglocalcfg

 The Splunk instance with the given settings in SPLUNK_HOME/etc/system/local/server.conf is missing the master_uri attribute and needs to be restarted. The master_uri attribute is required for the master node to communicate with the peer nodes and the search head cluster. The master_uri attribute specifies the host name and port number of the master node. Without this attribute, the master node cannot function properly. The Splunk instance also needs to be restarted for the changes in the server.conf file to take effect. The replication_factor setting determines how many copies of each bucket are maintained across the peer nodes. The search factor is a separate setting that determines how many searchable copies of each bucket are maintained across the peer nodes. The search factor is not specified in the given settings, so it defaults to the same value as the replication factor, which is 2. This is not a multi-site cluster, because the site attribute is not specified in the clustering stanza. A multi-site cluster is a cluster that spans multiple geographic locations, or sites, and has different replication and search factors for each site.

 A Technical Add-On (TA) is a Splunk app that contains configurations for data collection, parsing, and enrichment. It can also enable event data for a data model, which is useful for creating dashboards and reports. Therefore, before installing a TA, it is important to identify the number of scheduled or real-time searches that will use the data model, and to validate if the TA enables event data for a data model. The number of forwarders that the TA can support is not relevant, as the TA is installed on the indexer or search head, not on the forwarder. The installation location of the TA depends on the type of data and the use case, so it is not a fixed requirement

The following may explain the problem of why a colleague cannot see the src_ip field in their search results: The field was extracted as a private knowledge object, and the colleague did not explicitly use the field in the search and the search was set to Fast Mode. A knowledge object is a Splunk entity that applies some knowledge or intelligence to the data, such as a field extraction, a lookup, or a macro. A knowledge object can have different permissions, such as private, app, or global. A private knowledge object is only visible to the user who created it, and it cannot be shared with other users. A field extraction is a type of knowledge object that extracts fields from the raw data at index time or search time. If a field extraction is created as a private knowledge object, then only the user who created it can see the extracted field in their search results. A search mode is a setting that determines how Splunk processes and displays the search results, such as Fast, Smart, or Verbose. Fast mode is the fastest and most efficient search mode, but it also limits the number of fields and events that are displayed. Fast mode only shows the default fields, such as _time, host, source, sourcetype, and _raw, and any fields that are explicitly used in the search. If a field is not used in the search and it is not a default field, then it will not be shown in Fast mode. The events are tagged as communicate, but are missing the network tag, and the Typing Queue, which does regular expression replacements, is blocked, are not valid explanations for the problem. Tags are labels that can be applied to fields or field values to make them easier to search. Tags do not affect the visibility of fields, unless they are used as filters in the search. The Typing Queue is a component of the Splunk data pipeline that performs regular expression replacements on the data, such as replacing IP addresses with host names. The Typing Queue does not affect the field extraction process, unless it is configured to do so
