As covered in the "Cloud Computing Trends" and "Huawei Cloud Solutions" modules of the HCIA curriculum, OpenStack and FusionCompute occupy different layers of the cloud stack. Statement A is correct: OpenStack is a global open-source project maintained by a community, whereas FusionCompute is Huawei’s proprietary commercial virtualization platform (hypervisor).4

Statement B captures a fundamental technical difference. OpenStack is anorchestratoror "Cloud OS"; it lacks an internal hypervisor and must rely on external technologies (like KVM, Xen, or FusionCompute itself) to perform the actual virtualization. In contrast, FusionCompute is a standalonevirtualization suitethat includes the CNA (hypervisor) and VRM (management), allowing it to directly pool and manage physical hardware resources.

Statement C highlights the broader scope of OpenStack, which is designed to manage heterogeneous resources, including Bare Metal (Ironic) and Containers (Zun/Magnum). FusionCompute is a specialized tool primarily focused on Virtual Machines (VMs). Finally, Statement D refers to theMulti-tenancymodel. OpenStack was built for public and large private clouds, using "Projects" and "Tenants" to strictly isolate resources and billing between different organizations. FusionCompute is a lower-level resource manager that focuses on "Clusters" and "Resource Pools" rather than the complex tenant-based isolation logic found in high-level cloud platforms. In the Huawei ecosystem, FusionCompute often serves as the "Computing" component underneath a largerHuawei Cloud Stackor OpenStack-based solution, illustrating how these two technologies complement each other in a modern data center.

Distributed storage is a core concept in cloud computing and is emphasized in HCIA–Cloud Computing as a foundational technology for large-scale cloud platforms.

OptionAis true. Distributed storage is designed forhorizontal scalability, allowing storage capacity and performance to increase simply by adding more nodes.

OptionBis true. Unlike traditional centralized storage systems, distributed storage typically runs ongeneral-purpose x86 servers, reducing cost and improving flexibility.

OptionCis false. Distributed storagedoes not rely on traditional RAIDfor data protection. Instead, it usesdata replication or erasure coding, which are more suitable for large-scale distributed environments.

OptionDis true. Distributed storage eliminates the need for dedicated controller enclosures or disk enclosures. Storage resources are directly provided bygeneral-purpose servers, which aligns with cloud-native architecture principles described in HCIA materials.

In the official Huawei FusionAccess documentation, "Quick Provisioning" is a streamlined workflow designed to deploy multiple virtual desktops efficiently.1 For this process to succeed, several mandatory parameters must be defined to ensure the Virtual Machines (VMs) are created with the correct hardware and software specifications.

First, theComputer Type (A)is mandatory as it determines whether the desktops will be "Full Copy" (independent disks) or "Linked Clone" (shared base disk). This choice significantly impacts storage consumption and future maintenance. Second, aTemplate (D)is required because it serves as the "Golden Image" containing the pre-installed Operating System, drivers, and the Huawei Access Agent (HDA). Without a template, the system cannot instantiate the VM's disk content. Third, a targetHost (B)or resource cluster must be selected to provide the physical CPU and memory resources required for the VMs to run.

WhileSecurity Groups (C)are an important part of the network configuration, they are typically associated with a "Desktop Group" rather than being a mandatory field in the quick provisioning wizard itself. If no specific security group is selected, the system often applies a default policy. According to the HCIA curriculum, the core "Provisioning Plan" focuses on the source (Template), the deployment mode (Computer Type), and the destination (Host/Cluster). Ensuring these three parameters are correctly matched is vital for the automated provisioning engine to calculate resource availability and successfully trigger the VM creation on the backend FusionCompute platform.

====================

According to the Huawei HCIA-Cloud Computing documentation, security groups act as a distributed virtual firewall for Virtual Machines (VMs). Statement C is FALSE because FusionCompute allows a single Virtual Machine (or more specifically, a virtual NIC) to belong to multiple security groups simultaneously. This multi-group association allows for tiered security policies, such as having one security group for general web traffic and another for specific management access. When a VM belongs to multiple groups, the rules from all groups are aggregated to determine the final access control list.

Statement D is alsoFALSEbecause of the terminology regarding the "creation" location. In the FusionCompute architecture, security groups are logical objects created and managed within theVRM (Virtual Resource Management)portal, not "on the VMs" themselves. A security group exists independently of any specific VM; administrators create the group and define its rules first, and then they associate VMs with that group. Furthermore, users do not add rules "on VMs"; they add rules to the security group object in the management plane, which the system then automatically pushes to the corresponding CNA hosts where the VMs are running.

The other statements are technically accurate. Statement A is correct as Huawei’s security groups utilize the underlying LinuxiptablesorOVS (Open vSwitch)flow rules to filter packets at the hypervisor level. Statement B is also true; a VM's security group membership can be modified dynamically while the VM is in a running state without requiring a restart or causing a service interruption. This flexibility is a key feature of Huawei’s software-defined networking, allowing for real-time security adjustments in a dynamic cloud environment.

====================

Huawei FusionCompute provides a comprehensive virtualization platform with advanced management and scheduling capabilities.

Ais true. FusionCompute supportsdynamic resource adjustment, including CPU and memory scaling, helping applications adapt to workload changes.

Bis true. FusionCompute supportsx86 and Arm architectures, multiple storage backends, and mainstream operating systems such as Linux and Windows, ensuring broad application compatibility.

Cis true. SLA policies allow administrators to define priorities for virtual machines, ensuring that critical applications receive sufficient resources.

Dis true. FusionCompute supportsautomatic VM migration (such as DRS-like features)based on predefined policies to balance workloads and optimize system performance.

All listed statements correctly describe FusionCompute capabilities.

1-D, 2-C, 3-B, 4-A

In the Huawei FusionCompute architecture, network traffic is logically divided into specialized "planes" to ensure security, isolation, and optimal performance. TheBMC plane(Baseboard Management Controller) is dedicated to hardware-level management. It utilizes a dedicated network port on the physical host toenable remote access to the BMC system, allowing administrators to perform out-of-band tasks such as power control, BIOS configuration, and hardware health monitoring regardless of the OS state.

TheManagement planeis the communication backbone for the virtualization platform. It is used by the Virtual Resource Management (VRM) and Computing Node Agent (CNA) tomanage all nodes in a unified manner. All nodes in the cluster communicate on this plane to report resource status and receive management instructions. TheStorage planeis specifically reserved for data transmission between the compute hosts and the back-end storage infrastructure. This is theplane on which hosts communicate with storage units(such as LUNs or shared folders) to handle VM disk I/O.

TheService planeis the network segmentused by user VMsfor their actual service traffic. It carries the data produced and consumed by the applications running inside the virtual machines. Huawei documentation mandates the isolation of these planes—typically via VLANs—to prevent a "broadcast storm" or high data load in one plane (like Storage) from impacting the accessibility of the Management plane or the performance of user services.

As detailed in the Huawei FusionAccess documentation for the HCIA curriculum, the Huawei Desktop Protocol (HDP) is designed to optimize the user experience in Virtual Desktop Infrastructure (VDI). Statement A is correct: HDP features "Intelligent identification of video data."8 The protocol can automatically distinguish between standard GDI (Graphics Device Interface) desktop elements and active video streams.9 When video is detected, HDP switches to specialized compression algorithms (such as H.264 or H.265) to ensure efficient encoding and reduced bandwidth consumption.

Statement B is also a verified function. HDP employsDynamic Frame Rate Adjustment.10By monitoring the network quality (latency and packet loss) in real-time, the protocol can adjust the frame rate (e.g., from 60fps down to 30fps or lower) to maintain a smooth, jitter-free playback experience even on unstable or low-bandwidth links. Statement C is true as HDP supports multiple rendering modes. In "Multimedia Redirection," the video stream is decoded on theclientside (using local hardware acceleration), while in other modes, decoding occurs on theserver(VM) with the resulting images sent to the client. This dual-support flexibility ensures compatibility across various terminal types.

Statement D isincorrectbecause of the "maximum of 2K videos" limitation. According to the official HCIA-Cloud Computing V5.5 and FusionAccess technical guides, HDP@Media technology (multimedia redirection) explicitly supports4K UHDvideo playback, not just a maximum of 2K. While D correctly mentions "automatic reconnection" and "dynamic traffic adjustment," the resolution limit is technically outdated for the current Huawei cloud ecosystem. Thus, for the purposes of the HCIA certification, only A, B, and C are fully accurate representations of HDP's high-fidelity audiovisual capabilities.

Scenario

Operation

User data is stored in a network directory instead of a local host.

Folder redirection

The client IP address segment is not configured. Users can access VMs from any IP address segment.

Access control policy

A parallel-to-USB cable can be used to connect the parallel port device to the client.

Peripheral policy creation

In FusionAccess, policy management allows for deep customization of the user environment.Folder redirectionis a key feature for maintaining data persistence and centralized backup. It ensures thatuser data is stored in a network directoryrather than locally on the virtual machine's disk. This prevents data loss if a VM is refreshed or deleted, which is common in linked-clone pool environments.

Access control policiesare used to define the security boundaries of the VDI environment. When theclient IP address segment is not configured, it defaults to a permissive state whereusers can access VMs from any IP segment. Administrators typically use this policy to restrict access to known corporate subnets or specific VPN ranges to enhance overall security.Peripheral policy creationprovides support for legacy hardware or specialized equipment. By configuring these policies, aparallel-to-USB cable can be usedto bridge legacy parallel port devices to the modern USB ports of the client terminal, ensuring business continuity for specialized printing or diagnostic hardware.

Virtualization Technology

Description

KVM

Does not perform any hardware simulation.

Xen

Domain0 is the first VM to start on the host.

QEMU

Can simulate the implementation of an entire VM, including the CPU, memory, I/O device, USB, and NIC.

Libvirt

Can manage multiple virtualization platforms.

Huawei's technical materials differentiate between these technologies based on their specific roles within the virtualization ecosystem.KVM (Kernel-based Virtual Machine)is an open-source module within the Linux kernel. While it provides the core virtualization capabilities for CPU and memory, it is defined in the HCIA curriculum as a technology thatdoes not perform hardware simulationitself. Instead, it typically relies on hardware-assisted virtualization or integrates with other tools to handle I/O operations.

Xenis a Type-1 hypervisor that operates directly on the hardware. A unique feature of the Xen architecture isDomain0, which is a privileged virtual machine that starts first and provides the management environment and drivers for other guest VMs (DomainU). In contrast,QEMUis a pure software-based emulator. It is powerful because itcan simulate an entire VM, including all peripherals like the CPU, NIC, and USB. However, because it relies on software simulation, its performance is lower than hardware-assisted technologies unless it is used as a backend for KVM.

Finally,Libvirtserves as the universal management layer. It is a set of open-source library functions and APIs that allow administrators tomanage multiple virtualization platforms(including KVM, Xen, and VMware) using a standardized command set. It provides transparency to upper-layer management software by abstracting the complexities of the underlying hypervisor. Understanding how these technologies interact—such as KVM utilizing Libvirt for management and QEMU for I/O—is a critical learning objective for candidates preparing for the Huawei H13-511 exam.

In FusionCompute architecture,CNAandVRMhave clearly defined deployment models.

OptionAis false.CNA is deployed only on physical servers(compute nodes). It is responsible for interacting directly with hardware resources and cannot run inside a VM.

OptionBis true. When VRM is deployed on physical servers,active and standby VRM nodes must be installed on separate physical serversto ensure high availability.

OptionCis true. When VRM is deployed on virtual machines, the active and standby VRM VMs must be placed ondifferent hosts within the management clusterto avoid single points of failure.

OptionDis true. VRM supports deployment oneither physical servers or virtual machines, providing flexible management options.

Therefore, the correct answers areB, C, and D.
