According to the Huawei documents and resources, the troubleshooting operations for the AP onboarding failures are as follows:

• APS fail to be authenticated by the WAC: Whitelist the APS. The WAC can authenticate APs based on their MAC addresses or SNs. If an AP is not whitelisted on the WAC, it cannot be authenticated and onboarded.
• License resources on the WAC are insufficient: Expand the license capacity. The WAC can manage a limited number of APs based on its license. If the license resources are insufficient, some APs cannot be onboarded.
• APS fail to obtain IP addresses: Check the DHCP server. The APs need to obtain IP addresses from a DHCP server before they can communicate with the WAC. If the DHCP server is not configured or reachable, the APs cannot obtain IP addresses and onboard.
• APS fail to ping the WAC: Check the network between the WAC and APS. The APs need to ping the WAC to discover its IP address and establish a CAPWAP tunnel. If there is a network problem between the WAC and APs, such as incorrect VLAN configuration or firewall blocking, the APs cannot ping the WAC and onboard.

Therefore, APS fail to be authenticated by the WAC - c, License resources on the WAC are insufficient - b, APS fail to obtain IP addresses - d, APS fail to ping the WAC - a is the correct answer. References: : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/ap-onboarding-failures

According to the Huawei documents and resources, EAP termination and EAP relay are typical 802.1X authentication modes between the access device and authentication server. In EAP termination mode, the access device terminates EAP packets and encapsulates them into RADIUS packets. In EAP relay mode, the access device directly encapsulates the received EAP packets into RADIUS using EAP over RADIUS (EAPoR) packets2. Therefore, A and B are the correct answers. References: 2: https://support.huawei.com/enterprise/en/doc/EDOC1100086527

According to the Huawei documents and resources, the network planning suggestions for the solutions are as follows:

• Asset management: The RFID signal coverage distance is 25 m. Therefore, RFID signal coverage must be considered during AP deployment planning. Attach RFID tags on the surface or top of assets to prevent signals from being blocked.
• ESL: Shelves may be blocked in application scenarios. Therefore, shelf blocking must be considered during network planning. The shelves can be deployed in aisles to minimize obstacles toward integrated base stations.
• Smart healthcare: For applications that support regional positioning, positioning devices need to be deployed at key entrances and exits based on service requirements.

Therefore, Asset management - 2, ESL - 1, Smart healthcare - 3 is the correct answer. References: : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/asset-management : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/esl : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/smart-healthcare
